Slidemaster 10inch Mechanical Jackplate

Boat part number 8103697 is a new Slidemaster model mechanical jackplate from Legend Bass Boats, part number 317335 . Manufactured by R&R Design, part number unavailable. May be used on other boats.

This mechanical jackplate is constructed out of 1/2″ thick aluminum. It measures approximately 15 3/8″ W x 18 1/2″ H x 10 1/2″ D overall. Hosts (12) 1/2″ Dia. mounting holes. Features pre-installed holeshot plates. Please see photos for mounting pattern measurements.

Features:

• Inter-locking gibs
• Adjustable up and down from inside the boat
• 3″ to 4″ adjustment
• Fits up to 400 HP outboard engines
• 10″ Setback

Specifications:

• Boat Manufacturer: Legend Bass Boats
• Part Number: 317335
• Part Manufacturer: R&R Design
• Part Number: Unavailable
• Material: Aluminum
• Color: Gray / Black
• Overall Dimensions: 15 3/8″ W x 18 1/2″ H x 10 1/2″ D
• Set Back: 10″
• Engine: Up to 400 HP
• Lift: 3″ to 4″
• Mounts: (12) 1/2″ Dia. mounting holes
